UP300 3D Printer.

Features and description：

Three Separate Extruders - Optimized for Different Materials

Each extruder is designed specifically for a matching material type. One is for ABS and other high-temperature filaments, one for lower temperature filaments such as PLA, and the other is for TPU, a flexible polyurethane.

Dual Filtration System

Both PLA and ABS are “high emitters“ of UFP and VOC and it is essential for Health & Saftey compliance that you have a safe enviorment to print in. Manufacturing with plastic doesn’t have to be unhealthy. The X5 includes Tiertime’s 2018 air filtration system, specifically designed for large build chambers. Air is recirculated through separate HEPA and activated carbon filters, radically reducing toxic UFP and VOC emissions.

3. Control and Monitor Print Jobs with a 3” LCD Screen.

A 4.3-inch, full color, LCD touchscreen puts Tiertime Print Queue, print job settings and print job status right at your fingertips. Software-updateable, it can be enhanced for future features.

Waste Collection Tray.

A removable waste collection tray is positioned below the build platform to make cleaning the bottom of the printer’s enclosure a breeze.

5. Tiertime Print Queue

Tiertime’s new Print Queue allows multiple users to stack print jobs into a queue, accessible from the printer’s touchscreen and from Tiertime’s software. Any user on the network can become the queue’s administrator, controlling and re-ordering the print queue.

Print Directly from USB Stick.

The 2018 Tiertime line of 3D printers includes a spare USB port for loading print tasks from a USB memory stick. A print task is a sliced 3D model file with print settings embedded.

Ethernet Connection.

In addition to Wi-Fi, the UP300 includes a LAN Port for those preferring to work in a more secure, hard-wired network environment.

Printing Technology	MEM (Melted Extrusion Modelling)
Extruder	Single
Build Volume	205 × 255 × 225mm （XYZ）
Nozzle Diameter	0.2mm, 0.4mm, 0.6mm
Layer resolution	0.05/0.1/0.15/0.2/0.25/0.3/0.35/0.4
Extruder Maximum temperature	299℃
Extruder Maximum travel speed	200 mm/sec
XYZ accuracy XYZ	2, 2, 0.5 micron
Connectivity	USB cable, Wi-Fi, LAN and USB Stick
Touch Screen	4.3″ LCD
Printed object accuracy	±0.1mm/100mm
Build plate maximum temperature	100℃
Calibration and Leveling	Automatic Nozzle Height and Automatic Leveling
Print Surface	Perf Glass or Flex Glass, Heated
Enclosure	Full
Dual Filtration System	HEPA and active carbon filters
Print Resume on Power Interrupt	Yes
Pause to change the type of filament	Yes
Out of filament detection	Yes
Filament Compatibility	UP Fila ABS, ABS+, PLA , TPU, and more
Filament Diameter	1.75mm
Filament Spool Compatibility	500g - 1000g
Print queue	Yes
Compatible with 3rd Materials	Yes
	Physical dimensions
Machine dimensions	500x523x460 mm (19.6″ x 20.5″ x 18.1″)
Net weight	30KG
	Power requirements
Input	110-240VAC，50-60Hz，90W
Extra USB Input for add-on	5V, 1A
	Software
Software	UP Studio
Supported OS	Windows 7/8/10, Mac OS X, iOS 8.x/9.x
Importable file formats	up3, .ups, .stl, .obj, .3mf, .ply, .off, .3ds, .gcode
Preview support structures	Yes
Editable support structures	Yes
